Runda Racking
1 / 5
| RD-33# 300KG | |||
|---|---|---|---|
| Load capacity | 300KG / Layer | ||
| Layers | Standard is 4 layers (can be custom made) | ||
| Colour | Gray white / Sand blue / Customizable | ||
| Specifications | Length: 2000 mm | Width: 600 mm | Height: 2000 mm | ||
| Features | Removable shelves reduce the packaging volume while maintaining the same load-bearing capacity, saving a lot of transportation costs and improving product competitiveness. | ||
| 40HQ Capacity | A 40HQ high container can accommodate 425 sets of 200kg shelves. With a carefully designed structure, it is possible to reduce the packaging volume by 40% while maintaining the same load-bearing capacity. | ||
| Load/KG | Laminate thickness | Column specification | Crossbeam specifications |
|---|---|---|---|
| 100KG | 0.30 mm | 50*25*0.5 mm | 50*30*0.5 mm |
| 200KG | 0.35 mm | 70*35*0.7 mm | 60*35*0.6 mm |
| 300KG | 0.50 mm | 60*30*1.0 mm | 70*33*1.0 mm |
| 600KG | 0.50 mm | 70*33*1.4 mm | 70*35*1.2 mm |
In order to have a better understanding of our product, please allow us to remind you with the following three tips:
The standard dimensions of the RD-33 model are 2000 mm in Length, 600 mm in Width, and 2000 mm in Height. It features a standard load capacity of 300KG per layer.
Yes. While the standard build comes with 4 layers, custom amounts of layers are available. Standard color options include Gray White and Sand Blue, and we support fully customizable colors to match your branding or warehouse needs.
The optimized structural design allows the shelves to be fully disassembled. This reduces the overall packaging volume by 40% while preserving the high load-bearing performance, drastically reducing shipping fees and increasing market competitiveness.
We produce configurations built for different weight capacities: 100KG (0.30mm laminate), 200KG (0.35mm laminate), 300KG (0.50mm laminate), and heavy-duty 600KG (0.50mm laminate with reinforced columns and crossbeams).
Due to the space-saving structure, a single 40HQ high container can accommodate up to 425 complete sets of the 200kg load capacity shelves.
We provide one-stop, customized solutions for diverse environments, including heavy-duty warehouse storage, supermarket display shelving, mezzanine floor systems, and specialized mobile growing frames.
